Blaze-WAFER-EHL: 3.5" Single Board Computer (SBC)
Intel® Atom® x6425RE with Quad LAN, Triple Display & Wide Range 9V-36V
Key features
- Compact 3.5" form factor engineered for embedded equipment integrators
- Wide operating temperature support up to +85°C with optional heat spreader
- Triple independent display support (HDMI + DP + LVDS)
- Embedded Intel Programmable Services Engine (PSE) for real-time industrial I/O
- 15-Year longevity commitment for medical and transportation OEMs
Technical specifications
| Processor | Intel® Atom® x6425RE (Quad Core 1.9GHz, 12W Industrial) |
|---|---|
| Form factor | 3.5" SBC (146mm x 102mm) |
| Operating temperature | -40°C to 85°C |
| Power input | 9V ~ 36V DC Single Input |
| Memory | 32 GB DDR4-3200 Onboard / SODIMM |
| Storage | 1x M.2 2280 M-Key NVMe + 2x SATA III 6Gb/s ports |
| Expansion | 1x M.2 2230 E-Key, 1x M.2 3042 B-Key |
| Display output | 1x HDMI, 1x DisplayPort, 1x Dual-Channel 24-bit LVDS / eDP |
| LAN | 4x Intel® I226-IT 2.5GbE |
| Serial | 4x RS-232/422/485 header |
| Longevity | 15 years |
| Board Size | 3.5" Form Factor (146 x 102 mm) |
| Power Consumption | Typical 12W, Max 22W |
| Audio Controller | Realtek ALC888S HD Audio |
| GPIO | 8-bit Digital I/O |
| Operating Humidity | 5% ~ 95% non-condensing |
Applications
- Self-Service Kiosk Terminal Controller
- Medical Diagnostic Equipment Subsystem
- Robotic Controller Main Board
- ATM & Vending Machine Automation
