Blaze-PUZZLE-IN001: 1U Rackmount Network Security Appliance
13th Gen Intel Core / Xeon E-2300 with 4x 10GbE SFP+ & Smart LAN Bypass
Key features
- Enterprise SD-WAN and UTM firewall platform with hardware crypto acceleration
- 4x 10GbE SFP+ optical fiber uplink ports for high-throughput bandwidth
- Redundant hot-swappable 300W power supplies ensuring 99.999% uptime
- Intel® QuickAssist Technology (QAT) for line-rate packet encryption
- LCM Display module on front panel for IP status and diagnostics
Technical specifications
| Processor | Intel® Xeon® E-2378G (8 Cores / 16 Threads 2.8GHz) |
|---|---|
| Form factor | 1U 19" Rackmount |
| Operating temperature | 0°C to 45°C |
| Power input | Redundant 300W 80-Plus Gold AC Power Supply |
| Memory | 128 GB DDR4-3200 ECC UDIMM |
| Storage | 2x 2.5" Hot-swappable SATA III SSDs + 1x M.2 NVMe |
| Expansion | 1x PCIe x16 Gen4 slot for Network Interface Card (NIC) |
| LAN | 8x 2.5GbE RJ45 (with 2 pairs LAN Bypass) + 4x 10GbE SFP+ |
| Serial | 1x RJ45 Console Port + 1x DB9 RS232 |
| Longevity | 10 years |
| Form Factor | 1U Rackmount (438 mm x 450 mm x 44 mm) |
| Power Supply | 1+1 Redundant 300W AC Power Supply |
| Cooling | 3x Smart PWM Cooling Fans |
| Expansion Module Bay | 1x Blaze Network Module (8x GbE / 4x 25GbE option) |
| Management | IPMI 2.0 Dedicated Management Port |
Applications
- Enterprise Cyber Security Firewall & UTM
- 5G Open RAN Edge Server
- SD-WAN uCPE Gateway
- Industrial OT Network Security Inspector
