Blaze-FLEX-100AI: NVIDIA Orin NX Edge AI Box
Compact 100 TOPS AI Vision Gateway with 4x PoE GMSL2 Camera Inputs
Key features
- Delivers up to 100 TOPS AI inference speed at low power consumption (25W Max)
- Direct support for 4x GMSL2 automotive cameras with sub-millisecond synchronization
- Dual Isolated CAN Bus 2.0B / CAN-FD interfaces for vehicle telemetry
- Pre-loaded with Ubuntu 22.04 LTS, NVIDIA JetPack 6.0 SDK, and DeepStream SDK
- Designed for Autonomous Mobile Robots (AMR), AGVs, and smart logistics trucks
Technical specifications
| Processor | NVIDIA® Jetson Orin™ NX (16GB RAM, 100 TOPS AI Performance) |
|---|---|
| Form factor | Compact AI Box |
| IP rating | IP50 |
| Operating temperature | -25°C to 65°C |
| Power input | 12V ~ 24V DC Input |
| AI acceleration | NVIDIA Ampere Architecture GPU with 1024 CUDA Cores & 32 Tensor Cores |
| Memory | 16 GB LPDDR5 |
| Storage | 128 GB NVMe M.2 2280 SSD |
| Expansion | 1x M.2 3052 (5G module), 1x M.2 2230 (Wi-Fi 6) |
| Display output | 1x HDMI 2.1 (4K@60Hz) |
| LAN | 4x Gigabit PoE LAN (or 4x GMSL2 Automotive FAKRA camera connectors) |
| Serial | 2x CAN Bus 2.0B / CAN-FD + 2x RS-232/485 |
| Longevity | 10 years |
| AI Engine | NVIDIA Jetson Orin NX 16GB module |
| GPU Cores | 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores |
| CPU Cores | 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
| CAN Bus | 2x Isolated CAN-FD channels |
| Dimensions | 180 mm x 135 mm x 50 mm |
Applications
- AMR Autonomous Navigation & Obstacle Avoidance
- Agricultural Drone & Robotic Harvester AI Vision
- Intelligent Forklift Fleet Collision Avoidance
- Real-time Retail Analytics
