Blaze-eBOX-300DIN: Compact Ultra-Rugged DIN-Rail Industrial PC
Intel Alder Lake-N N97 with 4x 2.5GbE LAN & Wide -40°C~70°C Operating Temp
Key features
- Palm-sized aluminum chassis designed specifically for space-constrained control cabinets
- Integrated DIN-rail and wall mount brackets pre-installed
- 4x 2.5GbE high-speed LAN ports ideal for machine vision and Modbus TCP networking
- Wide operating temperature range -40°C to 70°C without fan airflow
- Hardware TPM 2.0 cryptographic chip integrated for IEC 62443 cyber compliance
Technical specifications
| Processor | Intel® Processor N97 (4 Cores, up to 3.6GHz, 12W TDP) |
|---|---|
| Form factor | Ultra-Compact DIN-Rail Box |
| IP rating | IP54 |
| Operating temperature | -40°C to 70°C |
| Power input | 9V ~ 36V DC Terminal Block |
| Memory | Single Channel DDR5 4800MHz up to 16GB |
| Storage | 1x M.2 2280 NVMe PCIe x2 SSD |
| Expansion | 1x M.2 3052 B-Key (5G), 1x M.2 2230 E-Key (Wi-Fi 6) |
| Display output | 1x HDMI 2.0 (4K@60Hz), 1x DisplayPort |
| LAN | 4x Intel® I225-V 2.5GbE RJ45 |
| Serial | 4x DB9 RS-232/422/485 (Hardware Auto Flow Control) |
| Longevity | 15 years |
| CPU | Intel® Processor N97 (12W TDP) |
| Power Protection | OVP, UVP, Reverse Polarity Protection, Surge 3kV |
| Watchdog Timer | Programmable 1~255 sec/min |
| Construction | Heavy duty extruded aluminum heatsink top |
| Dimensions | 145 mm x 110 mm x 55 mm |
| Weight | 1.2 kg |
Applications
- Substation Automation & Smart Grid SCADA
- Solar & Wind Farm Data Concentrator
- PLC Automation Control Cabinet Gateway
- EV Charging Station Management Unit
